Description
| Type de produit | Modem/Routeur |
|---|---|
| La désignation | Tenda AC1200 |
| IEEE Standards | IEEE 802.3、IEEE 802.3u、IEEE 802.3ab |
| VDSL2 Standards | ITU G.993.2, Up to 17a 、ITU-T G.993.5 (G.vector)、ITU-T G.998.4 (G.INP) |
| Interface | 3 10/100 RJ45 LAN Ports, 1 10/100/1000 RJ45 LAN/WAN Port, 1 RJ11 Port, 1 USB 2.0 Port |
| Bouton | WPS Button Wireless On/Off Button Power On/Off Button Reset Button |
| Alimentation de puissance | 12V 1.5A |
| LED | Power、Internett、USB、WPS、WLAN 2.4G、WLAN 5G、LAN(1-4） |
| Normes sans fil | IEEE 802.11a/n/ac 5GHz IEEE 802.11b/g/n 2.4GHz |
| Vitesse sans fil |
867Mbps at 5GHz
300Mbps at 2.4GHz Puissance de transmission
2.4GHz <20dBm(EIRP)
5GHz <23dBm(EIRP) |
| Puissance de transmission | 2.4GHz <20dBm(EIRP) 5GHz <23dBm(EIRP) |
| Sécurité sans fil | 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA-PSK2 encryptions, Wireless MAC Filtering |
| Protocols |
Supports IPv4 and IPv6
|
| ATM/PPP Protocols | ATM Forum UNI3.1/4.0, PPP over ATM (RFC 2364), PPP over Ethernet (RFC2516), IPoA (RFC1577/2225), MER\IPoE (RFC 1483 Routed), Bridge (RFC1483 Bridge), PVC – Up to 8 PVCs |
| Quality of Service | ATM QoS, Bandwidth Control |
| Gestion | Web Based Con guration(HTTP), Remote management, command Line Interface, SSL for TR-069, SNMP v1/2c, Web Based Firmware Upgrade, Diagnostic Tools |
| Fonctions avancées | Parental Control, Network Address Translation(NAT), Port Mapping(Grouping), Static Routing, RIP v1/v2(optional), DNS Relay, DDNS, IGMP V1/V2/V3 |
| DHCP | Server, Client, DHCP Client List, Address Reservation, DHCP Relay |
| Partage USB | Support Samba(Storage)/FTP Server |
| Certification | CE、RoHS |
| Contenu de l’emballage | AC1200 Dual-Band Wireless VDSL2 Modem Router V1200*1 External Splitter*1 RJ11 DSL Cable*1 RJ45 Ethernet Cable*1 Power Adapter*1 Quick Installation Guide*1 |
