Description

Manufacturer

‍Manufacturer: XFX
Model Number: RX-665X8DFDY
Product Name: AMD Radeon™ RX 6650 XT
Product Description: XFX SPEEDSTER SWFT210 RADEON RX 6650 XT CORE Gaming Graphics Card with 8GB GDDR6 HDMI 3xDP, AMD RDNA™ 2
Short Description : XFX SPEEDSTER SWFT210 RADEON RX 6650 XT CORE Gaming Graphics Card
Launch Date: May 2022
UPC Number: 840191500350

Specifications

‍Bus Type: PCI-E 4.0 @ 8x

‍
Clock Speeds:
Base clock Up to: 2055 MHz
Game Clock Up To: 2410 MHz*
Boost clock Up to: 2635 MHz**

Stream Processors: 2048
Compute Units: 32
Memory Bus: 128 bit
Memory Clock: 17.5 Gbps
Memory Size: 8 GB
Memory Type: GDDR6
Card Profile: Dual Slot
Thermal Solution: Dual Fan

* »Game Clock » is the expected GPU clock when running in typical gaming applications, set to typical TGP (Total Graphics Power). Actual individual game clock results may vary.

** »Boost Clock » is the maximum frequency achievable on the GPU running a bursty workload. Boost clock achievability, frequency, and sustainability will vary based on several factors, including but not limited to: thermal conditions and variation in applications and workloads.

‍

Outputs

‍DisplayPort: 1.4 with DSC
HDMI™: 2.1 VRR and FRL
Output : Display Port 3
Output: HDMI 1

‍

Requirements

‍External Power: 1x PCI-E 8 pin connections
Minimum Power Supply Requirement: 500 watt
XFX Recommended Power Supply: XFX 600W PSU

‍

Certifications

RoHS

Package Contents

Installation Guide: 1

Estimated Dimensions & Weights

‍Card Dimension (cm): 24.1 x 13.1 x 4.1
Card Dimension (inch): 9.49 x 5.16 x 1.61
Master Carton Dimensions (cm): 47 x 41 x 37.5
Master Carton Dimensions (inch): 18.5 x 16.14 x 14.76
Master Carton Weight (Kg): 12.25
Master Carton Weight (lb): 27
Package Dimensions (cm): 36.5 x 19.8 x 12
Package Dimensions (inch): 14.37 x 7.80 x 4.72
Package Weight (Kg): 1.07
Package Weight (lb): 2.36
Units/Carton: 10

Technologies

AMD RDNA™ 2 Architecture
DirectX® 12 Ultimate
Hardware Raytracing
FidelityFX™
Radeon™ Anti-Lag
Microsoft® Windows® 10 Support
Microsoft® DirectX™ 12 Support
7nm Technology
GDDR6 Memory
PCI® Express 4.0 Support
AMD FreeSync™ Technology*
DisplayPort™ 1.4 with DSC
HDMI™ 2.1 VRR
Video Streaming up to 8K
AMD FidelityFX*
Radeon™ Image Sharpening*
Radeon™ Anti-Lag*
AMD Software: Adrenalin Edition
Game Driver Optimizations
OpenGL Support
OpenCL Support

‍

* Not compatible with Windows 7. For more information on Radeon™ technologies, visit: AMD.com/gamingdetails

‍

Key Features

Advanced 7nm GPU
PCI Express 4.0 Support
Radeon™ Image Sharpening
FidelityFX™
Radeon™ Anti-Lag
Microsoft® Windows® 10 Support
Microsoft® DirectX™ 12 Support
7nm Technology
AMD Virtual Super Resolution (VSR)
AMD Software Media Recording andStreaming
AMD FreeSync™ 2 HDR
AMD Frame Rate Target Control (FRTC)
AMD Eyefinity™ multi-display technology
AMD Software Performance Tuning
Displayport 1.4 w/ DSC
Dolby TrueHD and DTS-HD Master Audio Support
OpenGL Support
OpenCL Support
